What we are going to cover

Define Module Boundaries
High Level Benefits
Boundary Types
Tooling

Have you ever wondered where a new piece of functionality should live or where functionality currently resides?

What are Module Boundaries?

Rules for structuring your code
Define how different parts of your application interact
Enforced by ESLint or by npm script

Why are Module Boundaries Important?

Enhance code readability and maintainability
Facilitate easier testing and debugging
Promote reusability of code components

Applying Module Boundaries


// project.json for a library in NX
{
  "name": "my-app-admin",
  "$schema": "../../../../node_modules/nx/schemas/project-schema.json",
  "projectType": "library",
  "sourceRoot": "libs/my-app/feature-admin/src",
  "prefix": "my-app",
  "tags": ["type:feature", "scope:my-app", "platform:web"], // <-- Tags for boundaries
  "targets": {
    "test": {
      "executor": "@nx/jest:jest",
      "outputs": ["{workspaceRoot}/coverage/libs/my-app/feature-admin"],
      "options": {
        "jestConfig": "libs/my-app/feature-admin/jest.config.ts"
      }
    },
    "lint": {
      "executor": "@nx/eslint:lint"
    }
  }
}

Boundary Types as defined by NX

app: Servable application, e.g. a web app, mobile app, etc.
feature: Business logic, container/smart components
data-access: API access & state management

ui: Presentation components
utils: Pure code functions, formatters, DTO converters

What can use what?

app: can import all the things
feature: feature, data-access, ui, utils
data-access: data-access, utils

ui: ui, utils
utils: utils

What can use what?

Replace _ with -. Hyphens don't work well in Mermaid Charts

Basic Structure

Custom Types as defined by you

models: interfaces, types and enums
e2e-utils: reusable cypress commands for end-to-end and component testing

assets: Static assets, e.g. images, fonts, etc.
store: NGRX state management

How do we organize this mess?

Grouping Folders


  app/
    application
  libs/
    admin/ <-- Grouping Folder
      data-access-admin
      feature-admin
      ui-admin
      utils-admin
    roster/ <-- Grouping Folder
      data-access-admin
      feature-roster
      ui-roster
      utils-roster

Nesting Folders


  app/
    application
  libs/
    admin/
      data-access/ <-- Heavy Nesting
        admin
      feature/
        details
        profile
        shell
      ui/
        admin
      utils/
        admin

Finding Balance

Heavy Libraries


  libs/
    admin/
      data-access-admin  <--Library
      feature-admin  <--Library
        profile
        user-import
        user-list
      ui-admin   <--Library
        avatar
        list-item
      utils-admin  <--Library
        helpers

Library Heavy


  libs/
    admin/
      data-access <-- Everything is a library
      feature-profile
      feature-shell
      feature-user-import
      feature-user-list
      ui-avatar
      ui-list-item
      utils-helpers

Quick Benefit

How types help build pipeline

Going deeper with Scopes

Everyone Stays In Their Lane With Scopes

Let's Add Some Shared Stuff

Scopes Specificity

Small Apps

scope:admin
scope:roster
scope:shared

Monorepo

scope:application1
scope:application2

Specific

scope:application1:feature1
scope:application2:feature2

You can write code to automatically manage this.

Other Types of Boundaries

platform:mobile|web|desktop
framework:angular|react|typescript
component:core|bespoke
version:modern|legacy
developer:daniel|jacob

Quick Tip

Use NX Generators to automatically add module boundaries to new libraries.

Example


  // npx nx g app-lib-generator admin/ui-user-details
  // npx nx g app-lib-generator admin/ui-user-details --libType=ui --scopeTarget=app1

  const projectName = options.name.replace(///g, '-');
  const rootComponentName = options.name.slice(options.name.lastIndexOf('/') + 1);
  const componentName = names(rootComponentName);

  const removeUnitTests = options.libType === 'model';

  const projectRoot = `libs/${options.scopeTarget}/${options.name}`;
  const importPath = `@app/${options.scopeTarget}/${options.name}`;

  const ngOptions = {
    prefix: 'app',
    name: `${options.scopeTarget}-${projectName}`,
    directory: projectRoot,
    importPath,
    tags: `type:${options.libType}, scope:${options.scopeTarget}`,
    skipModule: true,
    unitTestRunner: removeUnitTests ? UnitTestRunner.None : UnitTestRunner.Jest,
    standalone: true,
    strict: true,
    flat: true
  };

  await angularLibraryGenerator(tree, ngOptions);

  // Remove unnecessary files

Enforce Module Boundaries


    "rules": {
        "@nrwl/nx/enforce-module-boundaries": [
        "error",
            {
                enforceBuildableLibs: true,
                depConstraints: [
                    {
                        sourceTag: "type:ui",
                        onlyDependOnLibsWithTags: ["type:ui", "type:utils"]
                    },
                    {
                        sourceTag: "type:feature",
                        onlyDependOnLibsWithTags: ["type:feature", "type:ui", "type:data-access", "type:utils"]
                    },
                    {
                        sourceTag: "type:data-access",
                        onlyDependOnLibsWithTags: ["type:data-access",  "type:utils"]
                    }
                ]
            }
        ]
    }

Enforce Module Boundaries


          {
            "rules": {
              "@nrwl/nx/enforce-module-boundaries": [
                "error",
                {
                  enforceBuildableLibs: true,
                  depConstraints: [
                    {
                      sourceTag: "scope:application1",
                      onlyDependOnLibsWithTags: ["scope:application1", "scope:shared"]
                    },
                    {
                      sourceTag: "scope:application2",
                      onlyDependOnLibsWithTags: ["scope:application2", "scope:shared"]
                    },
                     {
                      sourceTag: "scope:shared",
                      onlyDependOnLibsWithTags: ["scope:shared"]
                    },

                 ]
                }
              ]
            }
          }

Additional Settings


          {
            "rules": {
              "@nrwl/nx/enforce-module-boundaries": [
                "error",
                {
                  enforceBuildableLibs: true,
                  allow: ['@shared/**', '@features/**', '@store/**', '@services/**'], // Migration strategy
                  depConstraints: [
                    {
                      sourceTag: "scope:shared",
                      notDependOnLibsWithTags: ["scope:application1", "scope:application2"]
                    },
                    {
                      allSourceTags: ["scope:admin", "type:ui"],
                      onlyDependOnLibsWithTags: ["type:util"],
                      allowedExternalImports: ["@angular/core", "@angular/common"] // Allow Angular imports
                      bannedExternalImports: ["*router*", "@angular/common/http"] // Rejects Angular Router & http imports
                    }
                 ]
                }
              ]
            }
          }

Migrating to Module Boundaries

Identify a pattern you want to follow with your team
Setup ignore for old folders/paths as you migrate
Write a generator/executor to find libs without tags
Leave code better than you found it

Migration Step 1


  apps/
    admin/
      components/
      services/
      store/
      admin.component
    roster/


  apps/
    roster/
  libs/
    admin/
      feature-admin/ <-- Feature Lib
        components/
        services/
        store/
        admin.component

Migration Step 2


  apps/
    roster/
  libs/
    admin/
      feature-admin/
        components
        services
        store
        admin.component


  apps/
    roster/
  libs/
    admin/
      data-access-admin/ <-- previously services and store
      feature-admin/
        admin.component
      ui-admin/ <-- Previously components

Vanilla Angular Module Boundaries

They don't exist, but we can use a tool to enforce them

Sheriff

Example Sheriff Config


    import {noDependencies, sameTag, SheriffConfig } from '@softarc/sheriff-core';

    export const sheriffConfig: SheriffConfig = {
        modules: {
            // Manual configuration of modules
            'src/app/admin/feature': ['scope:admin', 'type:feature'],
            'src/app/admin/data': ['scope:admin', 'type:data'],
            'src/app/roster/feature': ['scope:roster', 'type:feature'],
            'src/app/roster/data': ['scope:roster', 'type:data'],

            'src/app/<scope>/<type>': ['scope:<scope>', 'type:<type>']
        },
        depRules: {
            root: ['*'],

            'scope:*': [sameTag, 'scope:shared'],

            'type:feature': ['type:ui', 'type:data', 'type:util'],
            'type:ui': ['type:data', 'type:util'],
            'type:data': ['type:util'],
            'type:util': noDependencies,
        },
    };

Sheriff ESLint Config


 const sheriff = require('@softarc/eslint-plugin-sheriff');
 module.exports = tseslint.config(
  // ... previous rules
  {
    files: ['**/*.ts'],
    extends: [sheriff.configs.all],
  },
);

Sheriff CLI



  npx sheriff init  // Creates your sheriff.config.ts

  npx sheriff verify main.ts // Verifies your module boundaries

Review

Module boundaries help us get and stay organized
Help developers find what they are looking for
Should be defined and modified by the team
